Advantage |
1.The famous brand engine match reasonable with the domestic gear box, which make full use of the engine power, reduce fuel consumption greatly and save cost for user.
2.It adopts the front axle four wheel driving, which improve the load capacity of front axle, overcome the overload factor of the front axle two tiers of the cross country telescopic boom truck, and make it is safer.
3.The horizontal oil cylinder provide steering for the rear axle. The steering angle is large. It reduces the min.turning radius of the whole machine, and makes passing performance of truck better. It is suitable for working in a limited space. It is flexible steering, which improve the operating efficiency of the whole machine.
| Products Description |
| Parameter name | unit | WSM1120 |
| Performance parameter | ||
| Rated load | kg | 12000 |
| Minimum distance from main hook to front end of car body | mm | 500 |
| Maximum lifting height of main hook | mm | 7250 |
| Maximum lifting height of auxiliary hook | mm | 9850 |
| Maximum forward reach of main hook | mm | 4710 |
| Maximum forward extension of subhook | mm | 8000 |
| Maximum forward load of subhook | kg | 2600 |
| Amplitude time (up/down) | s | 11.5/10.5 |
| Stretch time (stretch/retract) | s | 14.3/16.5 |
| Tilt time (forward roll/back roll) | s | 4/5 |
| Maximum driving speed (no load) | km/h | 30 |
| Climbing grade | % | 22 |
| Turning radius | mm | 4000 |
| Machine weight | kg | 14800 |
| Structural parameter | ||
| Long (secondary arm folded) | mm | 5100 |
| Wide | mm | 2180 |
| High | mm | 2400 |
| wheelbase | mm | 3200 |
| Wheel base (front/rear) | mm | 1600/1650 |
| Distance from the ground | mm | 260 |
| Standard configuration | ||
| Engine type | / | LR4A3LU国Ⅲ |
| Brand | / | Red East |
| Power/revolution | kw/rpm | 84.6/2200 |
| Service braking mode | / | Tongs and pans |
| Parking brake mode | / | Air pressure release |
| Tire (front/rear) | / | 9.00-20/16 |
| Turn | / | Full hydraulic pressure |
| Optional configuration | ||
| Engine type | / | QSB3.9-C125 |
| Manufacturer | / | Dong Kang |
| Power | kw/rpm | 93/2200 |
| Torque | Nm/rpm | 480/1600 |
Various national export standards are acceptable, and various configuration adjustments can be made according to customer requirements, including vehicle structure, engine, arm length, attachments, cockpit, etc.
|
Shipping |
|
Customer case |
| FAQ |
Q: How about delivery time?
A: We will delivery during 30 working days after get your deposit.
Q: How can you guarantee quality?
A: We have made and exported many sets and get good feedback.
And if install at your site, we can debug and test to insure machine working well.
