Telescopic Forklift

Our Service

We are able to provide you with the overall installation of complicated machinery and equipment. After installation, we will make inspection of the whole machine, operate equipment and provide you with testing data of install and operation. If you no need us install, we can guide you by video or mobile to ensure you complicate the machine installation.

First 12 3 4 5 6 7 Last 1/14

Why Choose Us

Our company

Fujian weisheng machine development co.,ltd was found in 2000, and covers an area of more than 24000 square meters..We are located in andong park, jinjiang economic development zone, quanzhou, is a professional equipment manufacturing enterprise specializing in the r&d, mamufacture,sales and service..

Our service

We provide you with the overall installation of complex mechanical equipment. After the installation is completed, we will inspect the whole machine, run the equipment and provide you with installation and operation test data.

Product application

Our products are widely used in warehouses, ports, warehouses, heavy logistics, warehouses and other fields that require forklift cargo.

Production market

We export to asia: India, philippines, thailand, malaysia, singapore, indonesia, vietnam, uzbekistan, kazakhstan, turkmenistan, etc.

Advantages of Telescopic Forklift

Reach and lift

The extendable boom enables these machines to lift loads to significant heights, ideal for stacking materials on multi-story structures or reaching over obstacles.

Attachment options

Telescopic forklift loaders can be outfitted with a variety of attachments, such as buckets, winches, and work platforms. This adaptability allows them to perform multiple tasks, reducing the need for multiple machines on-site.

Maneuverability

Telehandlers are designed to navigate through tight spaces and rough terrain, making them suitable for both indoor and outdoor applications.

Cost efficiency

By consolidating multiple functionalities into a single piece of equipment, construction companies can save on both equipment rental/purchase costs and space.

Safety

Modern telescopic forklift loaders come equipped with advanced safety features such as load moment indicators and stabilizers, minimizing the risks associated with heavy lifting.

Top 5 Uses for a Telescopic Forklift

Moving heavy loads
Transporting heavy materials from place to place is easy with a powerful telehandler. Crews can use different attachments for various heavy-lifting purposes. For example, the pallet fork attachment enables telescopic handlers to safely relocate heavy boxes, bricks or blocks.

Reaching high planes
Telehandlers go where forklifts can't. Crews can use these lifts to safely load materials onto high shelves, replace light fixtures, clean ceilings and more without investing extra money on more expensive machines like cranes. High-reaching telehandlers improve efficiency and minimize the risk of injury on the work site.

Clearing job sites
Starting and finishing jobs usually require extensive work to clear space and restore a location to cleaner conditions. Crews often use telehandlers with a broom or all-purpose bucket attachment to efficiently remove debris and waste products. Telehandlers are also useful for removing snow.

Repairing tall structures
Telehandlers allow crews to safely reach high points of tall buildings, statues and other similar structures. Many telehandlers feature no-slip floor pads and reliable railings to prevent accidents.

Caring for trees
With enhanced mobility and reach, telehandlers allow crews to access hard-to-reach points on trees to monitor health, prune branches, fill cavities and more.

Parameter

Model	Unit	WSM1-10100
Performance
Rated load (loading center500mm）	KG	10000
Forklift center（to the truck front）	mm	1500
Max. Lifting weight	mm	15000
Loading center（to the truck front）	mm	500
Max lifting height H2	Km/h	10000
Max. Extension distance L2	%	7100
Max. Driving speed	KG	30
Max. gradeability	%	25
Weight	KG	14500
Boom
Boom NO		3
Up time	s	13.5
Down time	s	11.5
Extension time	s	14
Retraction time	s	17
Front rotary time	s	6
Rear rotary time	s	5.5
Variation angle	°	-5 ～ 60
Size
Length（without fork）L	mm	6050
Width W	mm	2300
Height H	mm	2350
Front rotary A	mm	1500
Wheel base B	mm	3500
Rear rotary C	mm	1050
Wheel tread（front/rear） E	mm	1800
Min.ground clearance F	mm	400
Cab width M	mm	800
Min turning radius
Two wheel steering	mm	4850
Four wheel steering	mm	4450
*Fork sizeL1W1H1*	mm	120018075
Fork frame width	mm	1500
Standard
Engine model		LR6A3LU
Manufacturer		Yituo(Luoyang)diesel engine
Rated capacity		117.6kw/2400rpm
Emission		Station Ⅲ
Transmission mode		Hydraulic transmission
Gear（front/rear）		2/2
Driving mode		Front two axle driving
Steering mode		Rear two axle steering
Service braking		Caliper disc
Parking braking		Pressure release
Tire（front/rear）		11.00-20（4/2）
Optional
Engine model	QSB4.5-C160-30
Manufacturer	Dongfeng Cummins
Rated capacity	119kw/2200rpm
Rated torque	624Nm/1500rpm
Emission	Station Ⅲ
Transmission mode	Hydrostatic transmission
Gear（front/rear）	2/2
Driving mode	Four wheel driving
Steering mode	Four wheel steering
Service braking	Multi-disc wet
Parking braking	Hydraulic release
Tire	Solid tire

Packaging & Shipping

1. 40ft container loader one unit SLD50 telehandler ,remove the tyres
2. By RoRo and Bulk carrier for SLD50 telescopic forklift

productcate-937-590

Packaging & Delivery

Package Size	6800.00cm * 2400.00cm * 2600.00cm
Package Gross Weight	11500.000kg

FAQ

Q: What kind terms of payment can be accepted?

A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted

Q: Can you meet my special requirements?

A: Yes, we accept customization.

Q: What about the delivery time?

A: Generally, it will take about 10 to 20 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q: What about the warranty time?

A: 12 months after shipment or 2000 working hours, whichever occurs first.

Q: What about the Minimum Order Quantity?

A: The MOQ is 1 pcs.

We're professional telescopic forklift manufacturers and suppliers in China, specialized in providing the best customized service. We warmly welcome you to buy or wholesale high quality telescopic forklift for sale here from our factory. For price consultation, contact us.
