| Advantage |
Security configuration
Equipped with mirrors and reversing buzzer; optional reversing radar imaging system, this system multi-point monitoring, wide monitoring range, real-time image display, effectively change the vision of the back, and operate without blind zones;
The hydraulic circuits of luffing, telescoping, tilting and outriggers are all equipped with balance valves, ensuring safe and reliable operation.
Function expansion (multifunctional device)
In addition to the standard equipment, it can also be equipped with flat-head buckets, straw forks, adjustable forks, side shift fork, string rods, tire clamps, paper roll oil surge clamps, log clamps, aerial work bars, high-position forage attachments, lifting equipment, glass carrier, impact gun head, one machine with multiple functions to improve efficiency.
| Parameter |
Model | Unit | WSM1-18130 |
Performance | ||
Rated load | KG | 13000 |
Forklift center（to the truck front） | mm | 2200 |
Max lifting height H2 | Km/h | 17800 |
Max. Extension distance L2 | % | 13000 |
Max. Driving speed | KG | 28 |
Max. gradeability | % | 22 |
Weight | KG | 20500 |
Boom | ||
Boom NO |
| 4 |
Up time | s | 11.5 |
Down time | s | 9.5 |
Extension time | s | 14.5 |
Retraction time | s | 16.5 |
Front rotary time | s | 6 |
Rear rotary time | s | 5.5 |
Variation angle | ° | 75 |
Size | ||
Length（without fork）L | mm | 7450 |
Width W | mm | 2500 |
Height H | mm | 2480 |
Front rotary A | mm | 2250 |
Wheel base B | mm | 3700 |
Rear rotary C | mm | 1500 |
Wheel tread（front/rear） E | mm | 1800 |
Min.ground clearance F | mm | 450 |
Cab width M | mm | 800 |
Min turning radius | ||
Two wheel steering | mm | 5800 |
Fork sizeL1*W1*H1 | mm | 1200*200*75 |
Fork frame width | mm | 1500 |
| With leg | yes | |
Standard | ||
Engine model | LR6A3LU | |
Manufacturer | Yituo(Luoyang)diesel engine | |
Rated capacity | 125 kW /2200 rpm | |
Emission | Station Ⅲ | |
Transmission mode | Hydraulic transmission | |
Gear（front/rear） | 2/2 | |
Driving mode | Front two axle driving | |
Steering mode | Rear two axle steering | |
Service braking | Caliper disc | |
Parking braking | Pressure release | |
Tire（front/rear） | 17.5R25 | |
Optional | ||
Engine model | QSB5.9-C180-31 | |
Manufacturer | Dongfeng Cummins | |
Rated capacity | 132 kW / 2200 rpm | |
Rated torque | 480 Nm / 1600 rpm | |
Emission | Station Ⅲ | |
Transmission mode | Hydrostatic transmission | |
Gear（front/rear） | 2/2 | |
Driving mode | Four wheel driving | |
Steering mode | Four wheel steering | |
Service braking | Multi-disc wet | |
Parking braking | hydraulic release | |
Tire | Solid tire | |
| Diagram |
| Customer case |
| Shipping |
| Certificate |
| FAQ |
1. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.
2. What payment terms do you accept?
Normally 30% T/T in advance as deposit, balance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.
3. Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 45 days.
