1. Pilot control
Adopt proportional pilot control hydraulic system, accurate control, simplify operation procedure, reduce labor intensity, speed regulation performance (good performance of speed control), speed range wide.
2. Super traction
The Double-turbine hydraulic torque converter is best matched with the high quality turbocharged engine, the best matching box and bridge deceleration ratio, which makes the whole machine have super traction.
3. Good performance
The superior wheel forklift loader performance, can be used as wheel loader, the lifting cylinder with big diameter cylinder,the lifting force on the ground reached 34 tons.
| Parameter |
Item | Unit | WSM972T28 | ||
1 | Overall size of whole machine | Length(fork on the floor) | mm | 9360 |
2 | Width | mm | 3200 | |
3 | Height | mm | 3720 | |
4 | Machine parameter | Operating weight | Kg | 33000 |
5 | Max. Traction | KN | 230 | |
6 | Fuel tank capacity | L | 350 | |
7 | Hydraulic fuel tank capacity | L | 350 | |
8 | Wheel base | mm | 4000 | |
9 | Wheel tread | mm | 2435 | |
10 | Min.turning radius | mm | 8500 | |
11 | Grade ability(no-load/ full load) | % | 36/25 | |
12 | Min.Ground clearance | mm | 500 | |
13 | Working device geometric parameters | Max. height of lifting fork | mm | 3550 |
14 | Standard fork size(L*W*H) | mm | 1570*250*150 | |
15 | Operational capability | Load center distance | mm | 900 |
16 | Rated load lifting capacity (the entier) | Kg | 28000 | |
17 | Max. lift capacity | Kg | 30000(1600mm) | |
18 | Engine | Rated power/rated speed | Kw/rpm | 175/2200 |
19 | Combined oil consumption | L/H |
| |
| Factory |
Police academy came to our factory to study
| Feedback |
| Shipping |
| FAQ |
Q1:How big is your factory?
A1:Our factory is about 111389 square meters with around 100 workers.Our factory have experience for more than 20 years.
Q2:Can you purchase some parts for us?
A2:Of course. We can purchase and pay for you if you want to buy other goods from Chinese market.
Q3:Can you provide OEM service?
A3:We can provide customized products according to customers' requirements; both OEM and ODM are acceptable.
Q4:Do you have any certificates for your machine?
A4:All of our machine is coming with certificate of CE AND ISO etc.
